Pioneer 300 Zoom

The Pioneer 300 Zoom is a 300W 3200K or 5600K powered LED fresnel. Features motorized zoom range from 8° ~ 60°. It’s high power light output, high CRI, DMX, RDM, soft wash effect make this fixture a perfect replacement of the traditional 1K fresnels.

Key features

300W COB white LED
3200K or 5600K color temperature
1KW tungsten equivalent
CRI 97, R9≥90, TLCI 98, CQS 94
RDM, DMX control
4 dimmer curves selectable
8° – 60° motorized zoom
16 bit dimming
Flicker free with selectable PWM
Rotary, key, DMX control of dimmer and zoom
Silent operation for studio and theater use

Categories Theatre lights, Architecture lights, Cyclorama light, LED panels

Color temperature

2700K - 6500K tunable

Compact

2.2 KG only

Manual zoom

25° - 80°

Color rendition

CRI 95, R9≥90, TLCI 98, CQS 96

Specifications

Physical

Length: 230 mm (9.1 in.)
Width: 156 mm (6.1 in.)
Height: 279 mm (10.9 in.)
Net Weight: 2.2 kg (4.8 lb.) barndoor included

Physical

Length: 230 mm (9.1 in.)
Width: 156 mm (6.1 in.)
Height: 279 mm (10.9 in.)
Net Weight: 2.2 kg (4.8 lb.) barndoor included

Physical

Length: 230 mm (9.1 in.)
Width: 156 mm (6.1 in.)
Height: 279 mm (10.9 in.)
Net Weight: 2.2 kg (4.8 lb.) barndoor included

Physical

Length: 230 mm (9.1 in.)
Width: 156 mm (6.1 in.)
Height: 279 mm (10.9 in.)
Net Weight: 2.2 kg (4.8 lb.) barndoor included

Dynamic effects

Length: 230 mm (9.1 in.)
Width: 156 mm (6.1 in.)
Height: 279 mm (10.9 in.)
Electronic shutter effect: Instant open and blackout
Electronic dimming: 0 – 100%
Strobe and pulse effects: Variable speed and action, random strobe
Electronic shutter effect: Instant open and blackout
Electronic dimming: 0 – 100%
Strobe and pulse effects: Variable speed and action, random strobe

Control and programming

Control options: DMX, RDM, stand-alone
DMX channels: 1/2/3/5
Dimmer frequency: 1.2 – 24.0 KHz
DMX address setting: Control panel with LED display or via RDM
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
RDM function available for addressing and settings
Stand-alone programming: Control panel with LED display, preset, color marco available
